HCC SERIES
Horizontal Centrifugal Casting Machines
Introduction
Heavy-Duty, Export-Oriented Horizontal Centrifugal Casting Platforms Engineered for Global Foundries & Industrial Applications.
HCC Series Overview
The HCC Series represents Gautam Industries’ flagship horizontal centrifugal casting machine platform. Designed with heavy fabricated structures, precision drive systems, and export-compliant automation, the HCC Series supports applications ranging from automotive liners to ultra-large industrial rolls.
The platform is available in Standard (S), Medium (M), Heavy (H), and Extra Heavy (HH) duty classifications to match production load, alloy type, and casting geometry.
HCC Series Model Matrix
| Model | Max Dia (mm) | Max Length (mm) | Duty Class | Primary Applications | Automation Level |
| HCC-300 | 600 | 600 | S/M | Small Tubes, Sleeves | Semi Auto / PLC |
| HCC-350 | 600 | 700 | S/M/H | Automotive Liners | Semi Auto / PLC |
| HCC-520 | 1000 | 1100 | S/M/H/HH | Hydraulic Sleeves | Semi Auto / PLC / ACS |
| HCC-600 | 1000 | 1200 | S/M/H/HH | Steel Sleeves | PLC / ACS |
| HCC-800 | 1300 | 1600 | M/H/HH | Reformer Tubes | PLC / ACS |
| HCC-1000 | 1300 | 2000 | M/H/HH | Large Tubes | PLC / ACS |
| HCC-1200 | 1300 | 2400 | H/HH | Heavy Wall Tubes | Full ACS with Automation |
| HCC-1500 | 1300 | 3000 | H/HH | Sponge Iron Tubes | Full ACS with Automation |
| HCC-1700 | 1300 | 3400 | H/HH | Kiln Tubes | Full ACS with Automation |
| HCC-1800 | 1300 | 3600 | H/HH | Industrial Castings | Full ACS with Automation |
| HCC-2000 | 2000 | 4000 | H/HH | Petrochemical Tubes | Full ACS with Automation |
| HCC-2500 | 2000 | 5000 | H/HH | Heavy Rolls | Full ACS with Automation |
| HCC-3000 | 2000 | 6000 | H/HH | Steel Mill Rolls | Full ACS with Automation |
| HCC-4000 | 2000 | 7000 | H/HH | Ultra Large Rolls | Full ACS with Automation |
Duty Classification
S – Standard Duty: Moderate production & light alloy casting.
M – Medium Duty: Enhanced rigidity & torque control.
H – Heavy Duty: Thick-wall & high-alloy casting capability.
HH – Extra Heavy Duty: Large diameter, continuous industrial production.
Engineering & Export Highlights
- Stress-relieved heavy fabricated base structure
- High torque synchronized drive systems
- Variable frequency RPM control
- Dynamic balancing & vibration control
- PLC-based monitoring & automation integration
- International safety standard electrical panels
- Turnkey ACS automation compatibility
- Global installation & commissioning support
Industries Served
Oil & Gas
Heat Treatment
Automotive
Steel
Petrochemical
Marine
Aerospace
